SCR Thyristor BT145-800 pinout, Features and Specifications

In this post, we are going to explain the SCR Thyristor BT145-800: A Silicon Controlled Rectifier (SCR), also known as a thyristor, is a device commonly used for controlling high power in electrical circuits. It acts as a switch that can turn on and conduct current when triggered, but it cannot turn off by itself until the current drops below a certain level. It has three terminals named Anode (A), Cathode (K), and Gate (G). The anode and cathode carry the main current, while the gate is used to control the switching action.

SCR Thyristor BT145-800 pinout

SCR Thyristor BT145 Features

• Planar passivated high-reliability SCR.
• designed for medium-power AC switching.
• low gate trigger current (easy to drive).
• capable of handling large surge currents.
• It is suitable for phase control, AC power regulation, crowbar protection, and motor control.
• Plastic TO-220AB package with a good thermal performance.

SCR Thyristor BT145 Specifications
